S15W

S15W

Bridging the gap between compact and powerful, the S15W combines the portability and ergonomy of the S12W with the extended low-frequency performance of the S18W.

Featuring a finely tuned 15” neodymium woofer, custom-developed exclusively for this enclosure, the S15W delivers impactful bass response with a frequency extension that strikes the perfect balance. Enhanced with the latest 64-bit FIR filtering DSP power and control electronics, it integrates seamlessly with other Nítid-S series systems, offering precision phase alignment and effortless usability through its intuitive touchscreen interface.

With its refined aesthetics, recessed carry handles, and high performance, the S15W sets a new standard in versatility for professional audio setups.

Touchscreen control

Amate Audio’s latest generation DSP system management is integrated with 3rd generation Class D amplification. Colour touchscreen operation and monitoring of DSP system includes access to powerful presets – engineered by Amate Audio’s R&D team – that instantly configure your Nítid loudspeaker for the majority of common application environments within seconds, prior to rigging or installation.

Amplifier program power2000 W - Class D
Input sensitivity2 dBu – 1V
Input impedance50 KΩ Balanced
MainsUniversal switch mode Power Supply 85-265 V / 45-65 Hz
Average current draw4.5 A (Heavy duty musical program)
SPL (1m)129 dB continuos , 132 dB peak
Built-in DSP64-bit processing unit. Includes factory presets.
PresetsS-ALIGNED / LPF80 / LPF90 / LPF100 / CARD S-ALIGNED / CARD80 / CARD90 / CARD100
AD/DA converters24 bit – 48 kHz
Standby mode consumption4.8 W @230VAC
Adjustable delay line294 ms / 100 m
Crossover frequency80 Hz / 90 Hz / 100 Hz
Frequency response (-10 dB)35 Hz – 140 Hz (LPF100)
Components LF15″ woofer (4” voice coil)
Directivity (-6dB)Omnidirectional
Weight39.7 kg
Dimensions (HxWxD)463 x 630 x 680 mm
FinishMultilayer birch plywood with high resistant black Polyurea® coating
Grille2 mm powder coated steel with black acoustic mesh
Connectors1x XLR input / 1x XLR link / 1x AC PowerCon® input / 1x AC PowerCon® link

Data Sheet

Download

General user’s manual

Download

Architect specifications

Download

2D CAD drawing

Download

GLL EASE library S15W

Download

EASE FOCUS 3 v.3.1.260 + Amate Audio pack

Download

Protection Cover

NC-S12W - for S15W/S15WP

Telescopic Distance Rod

SP/CRTL - for S15W/S15WP

Safety Sling

SC-15 - for S15W/S15WP

User’s manual

M8 Rigging Eyebolt

ACR-M8 - for S15W/S15WP
