Xcellence is the response of Amate Audio to the challenge of creating high-end products, a compromise to deliver our best and share with you our passion, the search for the best sound.

Xcellence means combining the latest available technologies, an extreme care for the finest details and a user friendly design, in order to create a product that meets the most demanding applications with Xcellent performance.

Point Source

X102FD

2x 10” ACTIVE SELF-POWERED BI-AMPLIFIED SYSTEM

Amplifier Program Power: 2500 W (LF) + 500 W (HF) Class D Bi-amp

Frequency Response (-10dB): 58 Hz – 19 kHzº

Maximum SPL (1m): 136 dB (musical program)

Weight: 32 kg

Cluster Array

X12CLA

12″ ACTIVE SELF-POWERED CLUSTER / ARRAY SYSTEM, 48 bit – 96 kHz DSP

Amplifier Program Power: 1000 W (LF) + 500 W (HF) Class D Bi-amp

Frequency Response (-10dB): 58 Hz – 19 kHz

Maximum SPL (1m): 129 dB (musical program)

Weight: 31.5 kg

Cluster Array

X12CLD

12” TWO-WAY CLUSTER/ARRAY FOR EXTERNAL DSP + BI-AMPLIFICATION

Program Power: 1200 W (LF) + 140 W (HF)

Frequency Response (-10dB): 60 Hz – 2 kHz (LF)  / 800 Hz – 20 kHz (HF)

Maximum SPL (1m): 130 dB (LF) / 130 dB (HF) (musical program)

Weight: 29 kg

Line Array

X208A

2x 8” ACTIVE SELF-POWERED BI-AMPLIFIED SYSTEM 48 bit – 96 kHz DSP

Amplifier Program Power: 2400 W (LF) + 600 W (HF) Class D Bi-amp

Frequency Response (-10dB): 78 Hz – 18 kHz

Maximum SPL (1m): 130 dB (musical program)

Weight: 25 kg

Line Array

X208P

TWO-WAY LINE ARRAY MODULE FOR EXTERNAL DSP + BI-AMPLIFICATION

Program Power: 1000 W (LF) + 200 W (HF)

Frequency Response (-10dB): 78 Hz – 2k2Hz (LF) / 1k2Hz – 18 kHz (HF)

Maximum SPL (1m): 130 dB (LF) / 131 dB (HF) (musical program)

Weight: 22 kg

Line Array

X210A

2x 10” ACTIVE SELF-POWERED BI-AMPLIFIED SYSTEM, 48 bit – 96 kHz DSP

Amplifier Program Power: 2400 W (LF) + 600 W (HF) Class D Bi-amp

Frequency Response (-10dB): 70 Hz – 18 kHz

Maximum SPL (1m): 134 dB (musical program)

Weight: 37 kg

Line Array

X210P

TWO-WAY LINE ARRAY MODULE FOR EXTERNAL DSP + BI-AMPLIFICATION

Program Power: 1200 W (LF) + 300 W (HF)

Frequency Response (-10dB): 70 Hz – 2kHz (LF) / 1k2Hz – 18kHz (HF)

Maximum SPL (1m): 133 dB (LF) / 135 dB (HF) (musical program)

Weight: 33 kg

Line Array

X212AFD

2x 12”+ 4×6”+ 2×3” ACTIVE SELF-POWERED TRI-AMPLIFIED SYSTEM

Amplifier Program Power: 2000 W (LF) + 1000 W (MF) + 1000 W (HF) Class D Tri-amp

Frequency Response (-10dB): 42 Hz – 18 kHz

Maximum SPL (1m): 141 dB (musical program)

Weight: 64.6 kg

Subwoofer

X18T

18” ACTIVE SELF-POWERED SUBWOOFER, 48 bit – 96 kHz DSP

Amplifier Program Power: 2500 W Class D

Frequency Response (-10dB): 32 Hz – 130 Hz

Maximum SPL (1m): 133 dB (musical program)

Weight: 44.1 kg / 47.5 kg (with KR-18T)

Subwoofer

X218WFD

2x 18” ACTIVE SELF-POWERED SUBWOOFER, 64-bit DSP with FIR filters

Amplifier Program Power: 5000 W Class D

Frequency Response (-10dB): 25 Hz – 120 Hz

Maximum SPL (1m): 141 dB (musical program)

Weight: 99 kg

x14fd-amateaudio

Point Source

X14FD

14” COAXIAL ACTIVE SELF-POWERED
BI-AMPLIFIED SYSTEM

Amplifier Program Power: 1000 W (LF) + 500 W (HF) Class D Bi-amp

Frequency Response (-10dB): 48 Hz – 20 kHz

Maximum SPL (1m): 129 dB (musical program)

Weight: 23.2 kg
